Choose the engine produced with British Ricardo joint-venture technology, which conforms to National II emission standard, and Common rail, features low noise, large torque, energy efficiency, and environmental friendliness.
Choose dry, multi-disk and constant combining clutch which features big torque reserve and high reliability.
Choose 4F+2R mechanical gear-shifting gearbox, simply operating, conveniently maintaining, reliably using.
Choose dry and multi-disk turning clutch, manually operating with hydraulically-assisted, easily maintaining, lightly and conveniently operating.
Choose two stages, straight teeth, big modulus gear transmission, stronger carrying capacity, and higher reliability.
Adopt the luxury cab, overhead air-conditioning system, comfortable operating space.
Straight-tilt shovel, angle shovel, coal shovel, and more.
| SD10 Bulldozer | |
|---|---|
| Performance Parameter | |
| Total weight (kg) | 10000 |
| Max towing force (kN) | 95 |
| Engine | |
| Engine model | LR6A3-23 |
| Rated power / speed (kW/r/min) | 81 / 2300 |
| Fuel consumption of the engine (g/km·h) | ≤ 242 |
| Engine max torque (N·m) | 400 |
| Walking Performance | |
| Forward 1–4 gear (km/h) | 2.6 – 10.4 |
| Reverse 1–2 gear (km/h) | 3.7 – 6.7 |
| Chassis System | |
| Caterpillar track board width (mm) | 450 |
| Land pressure (kPa) | 54.4 |
| Overall Dimension | |
| Dimensions (L×W×H) (mm) | 4400 × 2960 × 3030 |
| Blade Parameter | |
| Bulldozer shovel (W×H) (mm) | 2960 × 960 |
| Blade max lifting height (mm) | 830 |
| Blade max digging depth (mm) | 350 |
| Rear Attachment | |
| Towing equipment / Ripper (optional) | Fixed type / Three-tooth |
| Vehicle Type | |
| Stranded vehicle type | — |
