| Total weight |
6600 KG |
| Shipping length |
6346 mm |
| Total height during transportation |
2800 mm |
| Transport width |
2200 mm |
| Tire center distance |
2400 mm |
| Counterweight ground clearance |
1035 mm |
| Number of tires |
8×750-16 |
| Boom length |
3560 mm |
| Stick length |
1900 mm |
| Max. Digging Height |
6550 mm |
| Max. Dumping Height |
5100 mm |
| Max. Digging Depth |
3380 mm |
| Max. Digging Radius |
6590 mm |
| Max. lifting height of earth shovel |
300 mm |
| Max. digging depth of dozer |
100 mm |
| Engine Model |
Yang Dong |
| Power |
60/55 KW |
| Cooling method |
Water-cooling Turbo |
| Operating Pressure |
22 MPa |
| Main pump |
SGP1A2XFZH9 (Shimazduo) |
| Hydraulic valve |
Korea |
| Shape |
Load Sensing System |
| (SAE) Bucket Capacity |
0.36 m³ |
| Climbing ability |
30° |
| Maximum digging force |
8200 N |
| Travel speed |
35 KM/h |
| Unit swing speed |
9–11 r/min |
| Hydraulic oil capacity |
— |
